In-frame overhaul kit Beta Marine Beta 38 | Beta 45T – Nanni N4.38

Description

With this in-frame overhaul kit, you replace the wear-sensitive parts of the 4-cylinder diesel engine of your Beta Marine Beta 38, Beta 45T or Nanni N4.38 without completely overhauling the engine block. An affordable alternative to the complete overhaul kit, intended for engines whose cylinders are still within tolerance. Since the cylinder head must be removed to replace the pistons, a complete gasket set is included so you can seal the engine properly and leak-free.

✔️ Affordable alternative to the complete overhaul kit
✔️ Includes complete gasket set — the head gasket is always required
✔️ For cylinders within tolerance; honing recommended

Kit contents

• 4× piston ring sets
• 4× connecting rod bearings
• 1× complete gasket set
• 8× connecting rod bolts

Note: not suitable for scratched or worn cylinders or after overheating. In that case, choose the complete overhaul kit.

Suitable for

• Beta Marine: Beta 38, Beta 45T
• Nanni: N4.38, Q1500 (genset)
• Phasor: K4-12.5 (genset)

OEM for reference

• 16292-03310, 1629203310 — head gasket
• 16394-03310, 1639403310 — head gasket
• 16394-03313 — head gasket
• 1G089-99352, 1G08999352 — upper gasket set
• 1G089-99365, 1G08999365 — lower gasket set
